详细信息品牌： HRT 型号： SUS420 加工定制： 是 是否标准件： 非标准件 样品或现货： 现货 是否进口： 非进口 类型： 钢球 用途： 轴承、电气、设备、仪器、仪表 材质： 不锈钢 尺寸： 1.5mm 420不锈钢球 简介 420不锈钢铬含量比440C低，一般应用于高耐腐蚀要求的产品。这种材料对淡水，水蒸汽，汽油，血液，汗水，酒精和食品有一定防锈能力。但不能通过40小时的盐雾测试。 世界各国牌号 AISI 420, JIS SUS 420, JI X20 CR13, Z40 C13, EN56D, Wks 1.4034 规格 0.5mm to 50.8mm 等级 G10/G25/G50/G100/G200/G500/G1000 硬度 HRC 45-55 特性 具有一定耐磨性及抗腐蚀性，硬度较高 用途 特殊轴承，耐磨轴承，特殊泵，循环球，打火机，笔 化学成分 C 0.15% Max Cr 12-14% Si 1.0% Max Mn 1.0% Max P 0.04% Max S 0.03% Max 机械性能 抗张强度- 275,000psi 密度- 7.74g/cc 供应广东红润泰钢球厂G25级SUS420材质1.5mm不锈钢珠 SUS420材质1.5mm不锈钢珠 1) 材料：不锈钢SUS420; 2) 直径:1.5mm; 3) 级别:G5~ G1000; 4) 证书:ISO-9001,TS-16949,ISO14001; 5) 硬度:≧ HRC 52. 6)特性：具有一定耐磨性及抗腐蚀性，硬度较高，其价格是不锈钢球中较低的一类,适用于对不锈钢普通要求的工作环境中。 7)应用：适用于各类精密机械、轴承、电气、设备、仪器、仪表、交通运输工具、家用电器等。多用于制造耐大气、水蒸气、水及氧化性酸腐蚀的零部件。 Stainless Steel Ball AISI 420 General Information Balls of this material have a lower chrome content than 440C, and are used in application where the more rigid corrosion resistance requirements can be relaxed. They have fair resistance to fresh water, steam, oil gasoline, blood, perspiration, alcohol and food environment. However will not pass 40 hours salt spray test. International Equivalents AISI 420, JIS SUS 420, JI X20 CR13, Z40 C13, EN56D, Wks 1.4034 Size Range 0.5mm to 50.8mm Grade Available G10/G25/G50/G100/G200/G500/G1000 Hardness HRC 45-55 Feature They are characterized by good hardness, corrosion resistance, wear and abrasion resistance. Applications Special bearings, anti-friction bearings, special pumps, recirculating balls, lighters, pens. Material Composition C 0.15% Max Cr 12-14% Si 1.0% Max Mn 1.0% Max P 0.04% Max S 0.03% Max Mechanical Properties Tensile Strength- 275,000psi Density- 7.74g/cc Ball　Diameter balls（kg） kgs per 1000 pcs No.of balls per kg type of bearings to which the ball is applied 时 inch 毫米 mm - 0.8000 2.00209 478470 1000082,100009/1.5,106009/1.5 - 1.0000 0.00408 245100 100008/2.5,1000083,2000083,1000092,95 (45)1060092,8001/1.5,770083 - 1.2000 0.00705 141840 96,906072,906092 - 1.3000 0.00893 111980 100084,2000084,1000093,62,106009/2.5,1060093, 80013,8060023,60073. 1820093,1830093,2106083,2006083,1080093,906093,3836093. - 1.4500 0.0124 80645 1060084 1/16 1.5875 0.016 62350 23,53,1000085,970092(970052),970093(970053), 970095(970055)640063 740063,136023,6023,906073,2830085,1080085 - 1.7500 0.0218 45871 1060085,1830085 - 2.0000 0.0326 30700 1000086,1000087,1000088,1000801,2000086, 1000094,1000095,7000807,55. 430078(2-002),640095,78075,1060089,106094, 1060095,1210801,7060015. 80014,380075,2830086,1106094,1006095,1006094,516053. 3/32 2.3812 0.055 18182 24,1000089,1000096,1380096,1380096,8060026, 8060034,8060035,6024,106096. 1006096,3106095,606016,7008903,906076,1830096,900803. - 2.5000 0.0637 15698 2060088 - 3.0000 0.110 9091 1000097,1820097. 1/8 3.1750 0.131 7634 25,16,34,1000098,1000099,1000806,1000807,1000808, 900903,900904.1000902,900805,970700,900706,900808, 900809,900810,1026,1027, 971077(971067),981075(981065),981077(981067),6073(6003). 980075(980055),980065,980077,6025,106034(76004),1080099, 60074(60064),80075,500066,526055,1008098,106025,22706k(706), 900907,900912,1740808,640075(640065),501065,1018,1035 - 3.5000 0.175 5717 1380099,1000810,7900812 5/32 3.9688 0.255 3922 17,18,19,35,26,27,28,56,66,86,89,1000900,1000901,1000903,780065 520026,530018k,530018k1,3180018,180027,7900813,980079, 980085,1029,981028,981077,(981067),7426815k(7130815).6017,6018, 6026,106018,136026,36017,36018,506057,536057,1008096, 796906(836906),796905(636905),796904(2-605),796705(2-606). 3/16 4.7625 0.441 2268 29,10009048,7000101,7000102,100,101,102, 102,200,901,690079(690069) 280701,(80701),80801，980811k，180102， 980087（980067), 80907)980906)，981078(981068), 6027,6102,6078(6008), 800620(6012),6076(6006),106028, 36019,36027,36028,36029,36100,36102,46100,46101,256500, 7426815(7710815),1200,1201,8100,8101,8102,8103. - 5.0000 0.510 1961 1000904,1000905,1000906,540822,7000910,700, 15/46 5.9531 0.860 1163 200,201,202,80902,180700,60902,6200,6202, 26202,776901,406900(2-610), 36200,46200,36202,46202,15604(2-601),3056202k. 1/4 6.3500 1.04 962 104,300,105,1000908,7000106,7000107,8107, 7000108,7000109,980704, 980705, 709,8203,704(100704),330078, 330088,1204,1301,1302, 1503,6104, 6703(6017), 1036909,688808(688908), 3056203,776701(676701), 7426824(7936824)98906(98206) 17/64 6.7469 1.25 800 203,301 9/32 7.1438 1.49 671 203,106,300,7000110,7000111,8108,700112, 7000113,20703,710,970705,8109, 970711,180205,180504,1205,1303,8110,1304,1504, 1505,1600,1601,8204,1602,1970819, 6203,26203,36203,198905k(108905),46203,3056204, 3056205,3756205,1136820, 688708,606925(3-615),106930(3-616). 5/16 7.9375 2.04 490 204,205,301,302,107,708925,108,7000114, 970205,940705,8000205(705),80905, 980700,530202(30804),180506,8205,1740817, 1206,1207,1506,1603,8206,6204, 6704(6020),26204,26205,116205,36204,46204,36205, 46205,3056304, 3086304,986711,688911,588911,776801. 3/8 9.5250 3.52 284 206,303,304,1000916,1000917,8116,905,20803,530206, 520806,140806,8117,1970826, 520206,1209,1210,1306,8207,1507,1508,1509,1510, 26704,8305,26704k(326704), 36206,688713(9688213),8113,8114,8115
